When selecting solar panels for your installation, the size of the solar panel is an important
factor to consider. Solar panels come in various sizes, and their dimensions can significantly
impact the overall energy output of your solar system.
Larger solar panels generally produce more power, but the cell technology they contain is
also crucial. Solar panel size can be measured in terms of power rating, with some panels
having higher power density despite being smaller in size. The key is to determine which
panels offer the most efficient use of space and cost-effectiveness for your rooftop. This might
mean using more small panels or fewer large panels, depending on your building.
Solar Panel Dimensions
The options for your rooftop solar system can be seen in the dimensions of solar panels.
Leading solar module providers such as AMPS offer various solar panel sizes, and not all will
be suitable for every household. The goal is to maximize power output within the available
rooftop space.
A typical residential solar system in the US is 6-8 kW, with a home rooftop array optimally
having 15-20 solar panels. For example, AMPS offers residential solar panels with a power
output of 370Wp to 430Wp. The highest power class of solar modules can often be smaller
than lower power modules due to advanced cell technology. Your installation partner will
explain these details during the consultation process.
Common Residential Solar Panel Sizes
Residential solar panels are typically determined by the number, size, and type of solar cells.
The most common solar cell size is 152-by-152mm (6-by-6 inches). New technologies have
led to larger cell sizes, resulting in higher power and potentially larger panel sizes.
Most solar panels contain either 60 or 72 solar cells (usually cut in half and labeled as 120-
half cell and 144-half cell). Panels with 60 cells are smaller and have a power rating of up to
300 Wp, while panels with 72 cells can produce over 400 Wp.
Solar modules with PERC technology and 400 Wp output typically measure around 1.9 meters
(74 inches) in height and 1 meter (39 inches) in width. Standard residential panels generally
have fewer cells and are shorter in length, usually around 1.65 meters (65 inches).
Commercial and Utility-Scale Solar Panel SizesCommercial and utility-scale solar panels are larger than residential panels to meet the higher
energy needs of businesses. These panels have higher wattage, often reaching 500-600 Wp,
and contain more solar cells, up to 96 cells (or 192-half cells). These panels are heavier and
require at least two installers for handling.
Factors Affecting Solar Panel Size Selection
Choosing the right solar panel size involves several considerations:
Solar Panel Structure
Consider the dimensions, cell technology, and cell composition of the solar panels. For
example, bifacial panels can generate electricity on both sides.
Available Roof Space
Evaluate your rooftop space with a trained installer. Assess areas for shading, irregular shapes,
and orientation (south-facing is ideal).
Energy Demands
Determine your energy consumption and whether you need to cover the entire roof or use
fewer, larger panels. Review previous energy bills for accurate planning.
Efficiency and Technology
Not all panels with the same dimensions offer the same power output. Consider cell types,
interconnection methods, and power optimization technology.
Geographic Location and Sunlight Availability
Factor in your location and sunlight availability. Optimal sizing balances performance and cost.
Excess energy can be stored in a battery system or fed into the grid for credits.
How Many Solar Panels Do I Need for My Home?
To determine the number of solar panels needed for your home, arrange a free consultation
with AMPS. Record your annual energy consumption in kilowatt hours (kWh) and divide it by
the average electricity produced per solar panel. Consider the solar irradiation your rooftop
receives per year.
Conclusion
There is a wide range of solar panel sizes on the market. Various factors determine the optimal
size for your rooftop. An experienced solar installer can guide you through this process, and
AMPS can recommend trusted partners to ensure your solar solution is efficient and cost-effective.
